Availability:
Shipping & Returns: Free Shipping. All The Time.
|
Magnification
|
25
|
|
Objective Lens Focal Length(mm)
|
470
|
|
Objective Lens Diameter(mm)
|
82
|
|
Objective Lens Type
|
Normal Lens
|
|
Prism type and effective light aperture
|
Off-axis roof prism(25mm Passage aperture)
|
|
Eyepiece Focal Length(mm)
|
18.5(Contact glass caliber27mm)
|
|
Eyepiece Lens Structure(#Elements/# Groups)
|
8/5(Ultra Flat Field Design)
|
|
Real Field of View
|
2.6°
|
|
Apparent Field of View
|
65°
|
|
Field of View(m/1000m)
|
45
|
|
Field of View(ft/1000yds)
|
135
|
|
Exit Pupil(mm)
|
3.3
|
|
Relative Brightness
|
10.9
|
|
Eye Relief(mm)
|
20
|
|
Interpupillary distance
|
54-76
|
|
Minimum Focusing Distance(m)
|
15
|
|
Length(mm)
|
485(Telescopic hood)
|
|
Width(mm)
|
226
|
|
Height(mm)
|
122
|
|
Weigh(kg)
|
4.7(magnesium alloy)
|
